Specification:
- MCU – STMicro STM32F7 Arm Cortex-M7 microcontroller @ 216 MHz with 2D graphics and JPEG accelerators
- Memory – 32MB RAM
- Storage – 64MB flash
- Connectivity – 2.4 GHz WiFi and BLE (ESP32) with onboard and external u.FL antennas
- USB – 1x Micro USB port for power and programming
- Expansion with through and castellated holes with up to 25x GPIO, 12x PWM, 6x analog inputs, 2x DAC, I2C, I2S input/output, SPI, UART, CAN Bus
- Misc – RGB LED, DFU Boot button
- Power Supply-5V via micro USB port
- 2-pin JST connector for 3.7V LiPo/Li-Ion battery; integrated charging circuit
- Dimensions – Adafruit Feather form factor
Description:
The Meadow F7 micro development kit incorporates 32MB flash, 2D graphics, and JPEG acceleration. This development kit includes a breadboard that helps to start building projects out of the box. The Meadow F7 micro development kit employs GPIO, PWM, I2C, SPI, CAN, and UART interfaces.
Applicable for:
Meadow projects are built as .NET framework class libraries, but the code is executed like an application on the Meadow hardware.
